    Huawei 02315233 SFP-FE-SX-MM1310 100M/155M 1310nm 2km LC Multi-Mode Module

    Ask Lasest Price
    Brand Name : HUAWEI
    Model Number : HUAWEI 02315233
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 500pcs/week
    Delivery Time : 3-7 work days
    • Product Details
    • Company Profile

    Huawei 02315233 SFP-FE-SX-MM1310 100M/155M 1310nm 2km LC Multi-Mode Module

    Huawei 02315233 SFP-FE-SX-MM1310 100M/155M 1310nm 2km LC Multi-mode Module

    Product Description:

    Product Code
    SFP-FE-SX-MM1310
    Transceiver form factor
    SFP
    Transmission speed
    Fast Ethernet
    Center wavelength (nm)
    1310
    Standard compliance
    100base-FX
    Connector type
    LC
    Applicable cable and maximum transmission distance
    Multimode fiber (50 μm or 62.5 μm diameter): 2 km
    Transmit power (dBm)
    -19.0 to -14.0
    Maximum receiver sensitivity (dBm)
    -30.0
    Overload power (dBm)
    -14.0
    Extinction ratio (dB)
    10
    Operating temperature
    0°C to 70°C (32°F to 158°F)
    Net Dimension(D x W x H mm)
    145 x 80 x 35

    Transmitter Optical Characteristics

    • Center wavelength [nm]: 1310 nm
    • Maximum Tx optical power [dBm]: -14.0 dBm
    • Minimum Tx optical power [dBm]: -19.0 dBm
    • Minimum extinction ratio [dB]: 10 dB

    Receiver Optical Characteristics

    • Rx sensitivity [dBm]: -30.0 dBm
    • Overload power [dBm]: -14.0 dBm

    Product Details:

    If you are interested, please let us know the specific model. We will provide the best service and the best price!
