Huawei SSN4SLD64(S-64.2B,LC) 03052966 OSN3500 7500 2-port STM-64 10G interface board
Huawei OSN3500 SLD64 single board has two functional versions, N1 and N4. N4SLD64 supports CWDM and DWDM color optical interfaces, but N1SLD64 does not. N4SLD64 supports single-fiber bidirectional optical modules, but N1SLD64 does not. N4SLD64 supports voltage performance detection and reporting, but N1SLD64 does not. The N4SLD64 board supports the PRBS function, but the N1SLD64 does not. Supports dual optical ports, can receive and send 2 channels of STM-64 optical signals, process 2 channels of STM-64 standard services or cascaded services, and adopt XFP optical module packaging. Supports optical module manufacturing information query and optical module performance report. Support laser default shutdown, laser switch setting and query. Support VC-12/VC-3/VC-4 services and VC-4-4c, VC-4-8c, VC-4-16c, VC-4-64c cascade services. Support section overhead processing of STM-64 signal. Support the setting and query of J0/J1/C2 bytes. Provides a wealth of alarms and performance events to facilitate equipment management and maintenance. Support multiplex section shared optical path protection. Provides 4 sets of K-byte processing capabilities, a single optical port provides 2 sets of K-byte processing capabilities, and one SLD64 board supports up to 4 MSP rings. Support VC-4 channel inner loopback and outer loopback functions.
Specification:
| Front Panel | ||
The front panel of the SSN4SLD64(S-64.2b,LC) has indicators, interfaces, a bar code, and a laser safety class label. | ||
| Valid Slot | ||
| OSN 3500: When cross-connect boards are IXCSA and SXCSA, the SSN4SLD64(S-64.2b,LC) can be installed in slots 7,8,11,12. | ||
| Feature Code | ||
| The number code that follows the board name in the bar code is the feature code of the board. The feature code of the SSN4SLD64(S-64.2b,LC) indicates the type of optical interface. | ||
| Board | Feature Code | Type of Optical Interface |
| SSN4SLD6402 | 02 | S-64.2b |
| Optical Interface Parameter | ||
| Parameter | Value | |
| Nominal bit rate | 9953280 kbit/s | |
| Line code pattern | NRZ | |
| Application code | S-64.2b | |
| Transmission distance (km) | 2 to 40 | |
| Type of fiber | Single-mode LC | |
| Operating wavelength range (nm) | 1530 to 1565 | |
| Launched optical power range (dBm) | -1 to +2 | |
| Receiver sensitivity (dBm) | -14 | |
| Minimum overload (dBm) | -1 | |
| Minimum extinction ratio (dB) | 8.2 | |
| Maximum -20 dB spectral width (nm) | 1 | |
| Minimum side mode suppression ratio (dB) | 30 | |
| Mechanical Specifications | ||
| Dimensions (mm) | 25.4 (W) x 235.2 (D) x 261.4 (H) | |
| Weight (kg) | 1.2 | |
Product details:
If you are interested, please let us know the specific model. We
will provide the best service and the best price!
