HUAWEI IXCSA SSN1IXCSA 03030DKL Ultra Cross-connect And Synchronous Timing Board
Product Desription:
Huawei OSN3500 Infinite Cross-connect and Synchronous Timing Board.
Higher order cross-connect capacity: 200 Gbit/s
Lower order cross-connect capacity: 40 Gbit/s
Access capacity: 155 Gbit/s.
Supports the SNCP protection at the VC-4-4c, VC-4-8c, VC-4-16c, VC-4-64c, VC-4, VC-12, VC-3, and AU-3 levels.
Supports VC-4-4c, VC-4-8c, VC-4-16c, and VC-4-64c concatenation services.
Supports a maximum of 40 linear MSP protection groups.
Supports a maximum of 12 ring MSP protection groups.
Supports the standard system synchronization clock.
Supports the real-time clock (RTC)
Supports the processing of the S1 byte to realize the clock protection switching.
Supports the extraction, insertion, and management of the SSM and clock ID.
Supports the 1+1 Hot Backup for the Cross-Connect and Timing Units protection schemes.
IXCS is an Infinite Cross-Connect board for Huawei OSN3500, provide 200G High order, 40G Low order Cross-Connect capacity and 155G Access capacity. IXCSA have N1 version, part number is 03030DKL.
Specification:
| Valid Slot | |
| OSN 3500: The SSN1IXCSA can be installed in slots 9 and 10 in the subrack | |
| Mechanical Specifications | |
| Dimensions (mm) | 40.0 (W) x 235.2 (D) x 261.4 (H) |
| Weight(kg) | 2.1 |
