    HUAWEI PFL1 SSN1PFL1 03053866 Huawei OSN3500 8xE1 Optical Processing Board

    Ask Lasest Price
    Brand Name : HUAWEI
    Model Number : SSN1PFL1
    Price : $100-$200
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 500pcs/week
    Delivery Time : 3-7 work days
    • Product Details
    • Company Profile

    HUAWEI PFL1 SSN1PFL1 03053866 Huawei OSN3500 8xE1 Optical Processing Board

    HUAWEI PFL1 SSN1PFL1 03053866 Huawei OSN3500 8xE1 optical processing board

    Product Desription:


    Huawei OSN3500 8xE1 optical processing board, PFL1

    The PFL1 is available in one functional version, N1.

    The PFL1 can be installed in slots 1-8 and slots 11-16.

    Processes E1 optical signals and overheads, and supports alarms, performance events, and maintenance features.

    Consists of the client-side receive/transmit module, mapping/demapping module, interface converting module, logic and control module, clock module, and power module.


    The PFL1 as a PDH processing board, which can be used on the OptiX OSN equipment series to receive/transmit and process 8xE1 optical signals.

    Specification:

    ParameterValue
    Basic functionsPFL1 can Process 8xE1 optical signals.
    Service processingReceives/Transmits and processes 8 x E1 optical signals.
    Supports transparent transmission in compliance with IEEE C37.94 to meet the transmission requirements of relay protection equipment in the electric power industry.
    Optical port specificationsSupports I-2M optical ports, which comply with standards defined by Huawei.
    Optical module specificationsSupports the detection and query of information about an optical module.
    Allows setting the on/off state of a laser and supports the automatic laser shutdown (ALS) function.
    Supports the usage and monitoring of eSFP optical modules, facilitating optical module maintenance.
    Overhead processingProcesses path overheads at the VC-12 level, such as J2 bytes.
    Alarms and performance eventsProvides various alarms and performance events, facilitating equipment management and maintenance.
    Maintenance featuresSupports inloops and outloops at optical ports.
    Supports warm resets and cold resets. Warm resets do not affect ongoing services.
    Supports the query of board manufacturer information.
    Supports in-service FPGA loading.
    Supports board software upgrades without affecting ongoing services.
    Supports the PRBS function.
    Hot board swapping.
    Protection schemeTPS protection is not supported.
    Parameters of the E1 optical interfaces of the OptiX OSN equipment
    Nominal bit rate2048 kbit/s
    Code typeNRZ
    Type of optical interfaceI-2M
    Transmission distance (km)0 to 2
    Operating wavelength range (nm)Single-mode: 1260 to 1360
    Multi-mode: 850
    Type of fiberSingle-mode LC/Multi-mode LC
    Launched optical power (dBm)-15 to -8
    Optical receiver sensitivity (dBm)-23
    Minimum overload (dBm)-8
    Minimum extinction ratio (dB)8.2
    Maximum -20 dB spectral width (nm)-
    Side mode suppression ratio (dB)-



    Product details:



    If you are interested, please let us know the specific model. We will provide the best service and the best price!
