    HUAWEI TOG TN52TOG 03030LNA TN52TOG01 WDM OSN6800 OSN8800

    Ask Lasest Price
    Brand Name : HUAWEI
    Model Number : Huawei TOG
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 500pcs/week
    Delivery Time : 3-7 work days
    • Product Details
    • Company Profile

    HUAWEI TOG TN52TOG 03030LNA TN52TOG01 WDM OSN6800 OSN8800

    HUAWEI TOG TN52TOG 03030LNA TN52TOG01 WDM OSN6800 OSN8800

    Product Description:

    The TOG board is mainly used to achieve cross-connection at the electrical layer.

    For detailed functions and features, refer to Table 1.

    NOTE:

    Only the OptiX OSN 8800 supports ODU0.

    Table 1 Functions and features of the TOG board

    Function and Feature

    Description

    Basic function

    TOG converts signals as follows:

    • 8 x GE<->8 x ODU0
    • 8 x GE<->4 x ODU1
    Client-side service type

    GE: Ethernet service at a rate of 1.25 Gbit/s. Supports GE optical signals and GE electrical signals.

    NOTE:

    The TOG board supports GE optical signals and electrical signals. For GE electrical signal transmission, it is recommended that the board be equipped with at most two GE electrical modules to facilitate fiber routing.

    Cross-connect capabilities

    OptiX OSN 8800: Supports the cross-connection of eight channels of ODU0 signals between the TOG board and the cross-connect board through the backplane.

    OptiX OSN 6800: Supports the cross-connection of four channels of ODU1 signals between the TOG board and the cross-connect board through the backplane.

    OptiX OSN 3800: Supports the grooming of four ODU1 signals from one board of the mesh group (consisting of four boards) to the other three boards belonging to the mesh group.

    OTN function
    • Supports the OTN frame format and overhead processing defined in the ITU-T G.709. The mapping process is compliant with ITU-T G.709.
    • Supports PM functions for ODU1/ODU0.
    Alarms and performance events monitoring
    • Monitors BIP8 bytes (Bursty mode) to help locate line failures.
    • Monitors OTN alarms and performance events.
    • Monitors parameters such as the bias current, temperature, and optical power of the laser.
    • Supports the remote monitoring (RMON) of Ethernet services.

    NOTE:
    The TOG board supports remote monitoring (RMON) only at the receive end .
    ALS functionSupports the ALS function on the client side.
    PRBS test functionNot supported.
    LPT functionSupported
    Test frameNot supported.
    Latency measurementNot supported
    IEEE 1588v2

    Supports the TC, TC+OC, BC, and OC modes when the client service is GE multiplexed using the GFP-T procedure (the service type is displayed as GE(GFP-T) on the U2000).

    NOTE:
    The TOG board supports only two channels IEEE 1588v2 signals.
    Physical clock

    When receiving GE(GFP-T) services on the client side, the board can support synchronous Ethernet processing instead of synchronous Ethernet transparent transmission.

    When receiving GE(TTT-GMP) services on the client side, the board can support synchronous Ethernet transparent transmission instead of synchronous Ethernet processing.

    Electrical-layer ASONSupported
    Protection scheme
    • Supports ODUk SNCP.
    • Supports client 1+1 protection.
    Ethernet service mapping modeSupports encapsulation of GE services in GE(GFP-T) or GE(TTT-GMP).
    Ethernet port working mode1000M Full-Duplex
    LoopbackWDM side-
    Client sideInloopSupported
    OutloopSupported
    Protocols or standards complianceProtocols or standards for transparent transmission (non-performance monitoring)IEEE 802.3z
    Protocols or standards for service processing (performance monitoring)

    ITU-T G.805

    ITU-T G.806

    ITU-T G.709

    ITU-T G.872

    ITU-T G.7710

    ITU-T G.798

    ITU-T G.874

    ITU-T M.3100

    ITU-T G.874.1

    ITU-T G.875

    ITU-T G.808.1

    ITU-T G.841

    ITU-T G.8201

    ITU-T G.873.1

    ITU-T G.694.1
