    Huawei OSN 9800 U16 Platform 400G Per Slot Capacity

    Ask Lasest Price
    Brand Name : HUAWEI
    Model Number : Huawei OSN9800 U16
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 500pcs/week
    Delivery Time : 3-7 work days
    • Product Details
    • Company Profile

    Huawei OSN 9800 U16 Platform 400G Per Slot Capacity

    Huawei OSN 9800 U16 Platform 400G per Slot Capacity​

    Product Description:

    The Huawei OptiX OSN 9800 Specifications:

    Specifications
    OSN 9800 U16
    OSN 9800 U32
    OSN 9800 U64
    Dimensions (HxWxD)
    847x442x295mm
    1900×498x295mm
    2200x600x600mm(with cabinet)
    Number of Service Slots
    14
    32
    64
    Switching
    Capability
    Optical
    Up to 20-degree C-D-C-G ROADM
    Electrical
    5.6Tbit/s universal switching
    6.4 /12.8Tbit/s universal switching
    12.8/25.6Tbit/s universal switching
    Number of
    Ports
    Max OTU4 Ports
    28/56
    64/128
    128/256
    Max 100GE Ports
    28/56
    64/128
    128/256
    Max OTU3 Ports
    28
    64
    128
    Max 40GE Ports
    28
    64
    128
    Max OTU2 Ports
    280
    640
    1280
    Max 10G Ports
    280
    640
    1280
    Max GE/2.5G Ports
    420
    960
    1920
    Max OTUC2 Ports
    14
    32
    64
    Max OTUC4 Ports
    7/14
    16/32
    32/64
    Channel Spacing
    50/100GHz fixed grid for 40/80-ch
    Flex-grid
    Wavelength Range
    DWDM: 1529.16 nm to 1560.61 nm (C Band, ITU-T G.694.1)
    Rate per Channel (Max.)
    100G, 200G, 400G, 1T, 2T
    Service Types Supported
    SDH, SONET, Ethernet, SAN, OTN, video
    Topology
    Point-to-point, chain, star, ring, ring-with-chain, tangent ring, intersecting ring and mesh
    Redundancy
    and Protection
    Equipment
    1+1 power input protection, 1+1 fan protection, M:N switch board protection, 1+1 controller protection
    Network
    OTN: Optical line protection, client 1+1 protection, ODUk SNCP, tributary SNCP, intra-board 1+1
    protection,LPT, ASON/GMPLS
    PKT: PW APS, Tunnel APS, LAG
    Optical Power Management
    ALS, AGC, ALC, APE, IPA
    Synchronization
    IEEE 1588v2, Sync-E
    2Mbit/s or 2MHz (with the SSM function), ITU-T G.703-compliant external clock source
    External clock source (1PPS+TOD)
    ASON/GMPLS
    Automatic network discovery
    ODUk/λ level protection and restoration
    5-Level SLA (Service Level Agreement) provisioning
    End-to-end service configuration
    Shared Risk Link Group (SRLG)
    Traffic engineering
    T-SDN
    Automation, IP+Optical , BOD
    Installation Rack
    ETSI/19 inch rack
    ETSI 300/600mm rack
    ETSI 600mm rack
    Heat Dissipation
    Fan
    Power Supply
    -48VDC/-60VDC
    Operation Environment
    Temperature:
    Long-term operation: 5°C to 40°C
    Short-term operation: -5°C to 45°C
    Relative humidity:
    Long-term operation: 5% to 85%
    Short-term operation: 5% to 90%


    Product Details:


    If you are interested, please let us know the specific model. We will provide the best service and the best price!
